Wind Turbine Blade Adapter Transport
Rotor blades are sensitive and extremely long, with a trend towards ever larger installations. Rotor blade lengths of up to 80 meters are not uncommon anymore. They can be transported in various ways with vehicles by CARRIST.
Telescopic Extendable Windmill Turbine Blade Trailer are a solid and economical solution for easy route sections. When space is limited, we can rely on the windmill rotor-blade adapters , wind blade lifter by CARRIST. Mounted on platform trailers, rotor blades can be picked up, positioned at an angle of up to 60°, pivoted as well as rotated around their own axis. Mounted on a quick-release plate, the rotor blades can be securely picked up and maneuvered around any obstacles. In areas with trees or buildings, hairpin turns or in the mountains – the fragile load is thus easily, safely and efficiently delivered to its destination.
Carrist Blade Adapter Rotor blades for wind power plants frequently present haulage companies with a difficult task. Especially when dealing with the “last mile”, the transport is often more difficult particularly when tight corners or obstacles have to be negotiated. It is for precisely these situations that the new adapter generation from CARRIST provides the right solution to avoid obstacles such as trees or buildings with the rotor blades even more effectively. Also on steep hills or narrow winding mountainous roads, the position of the rotor blade can be adapted to the route without any time loss. At the same time, a wind sensor warns against exceeding a parameterizable wind speed. The new rotor blade adapter can be mounted and transported on both on a pulled platform trailer combination as well as self propelled modules, and guarantees flexible transportation of rotor blades from different manufacturers through the quick release plate and thus maximum efficiency and cost-effectiveness in daily use.
Specifications of Wind Turbine Blade Adapter Transport
Number of Axle-line(n) | 2 | 3 | 4 | 5 | 6 |
Speed(km/h) | 580 | 580 | 580 | 580 | 580 |
Total Weight(t) | 6832.8 | 10249.2 | 13665.6 | 17082 | 20498.4 |
Rated Payload(t) | 61 25.8 | 91.5 38.7 | 122.8 52.4 | 152.5 64.5 | 18377.4 |
Dead Weight(t) | 7 | 10.5 | 13.2 | 17.5 | 21 |
Load Per Axle Line(t) | 34 16.4 | 34 16.4 | 34 16.4 | 34 16.4 | 34 16.4 |
Total Length(mm) | 3000 | 4500 | 6000 | 7500 | 9000 |
Total Width(mm) | 3000 | ||||
Height(mm) | 1175 ±300 | ||||
Axles Distance(mm) | 1500 | ||||
Wheels Distance(mm) | 1800 | ||||
Tyre Specification | 215/75R17.5 | ||||
Rim Specification | 6.00-17.5 | ||||
Number of Tyre | 16 | 24 | 32 | 40 | 48 |
Max.Turning Angle of Wheel | 55° | ||||
Min.Turning Radius(mm) | inner 450 | inner 1500 | inner 2600 | inner 1500 | inner 2000 |
outer4070 | outer 5800 | outer 7600 | outer 5800 | outer 6700 |
