Girder Bridge Trailer on Sale

CARRIST VEHICLE :The basic structure of the bridge beam transport vehicle is to bridge the beam frame for load on the front and rear separated transport modules. The transport object is "lifted" by the beam frame in the air, and the load is transferred to the front and rear multi-axle transport modules through the base of the beam frame, so as to realize load sharing. Since there is no wheel restriction under the bearing surface of the beam frame, the height of the overall transport object can be controlled very low, or even directly lowered to the ground, which is very beneficial for some occasions with requirements for transport height; It is very convenient and safe to load and unload goods on the bridge girder transporter. Some types can be realized by their own functions without the assistance of lifting equipment; In addition, the split transport vehicle structure is also very flexible. Even if the total length of the body is very long, it is not difficult to turn at large angles.
