24Ft HVLS Ceiling Industrial Fan
Carrist 24Ft High volume fans are the newest cooling and ventilation option available for industrial,commercial and agricultural places. These large fans, which range in size from 12 to 24 feet, provide energy-efficient air movement throughout large open space saving more energy cost than small size high-speed fans.
Warranty: 5 year for all components.fan hub and blades for lifetime.
MOQ: 1 set
Product Details
| Carrist HVLS FAN KX series Specification | |||
| Model: | KX-4900 | KX-6100 | KX-7300 |
| Max diameter: | 4.9meter | 6.1meter | 7.3meter |
| Max diameter: | 16Ft | 20Ft | 24Ft |
| Wind load: | 11300m3/min | 12500m3/min | 14100m3/min |
| Fan weight: | 74Kg | 97Kg | 110Kg |
| Max speed: | 75rpm | 65rpm | 55rpm |
| Power: | 1.5Kw | 1.5Kw | 1.5Kw |
| Full load current: | 2.4A / 380V | 3.5A/380V | 3.5A/380V |
| Carrist HVLS FAN KX series Specification | |||
| Model: | KX-4900 | KX-6100 | KX-7300 |
| Max diameter: | 4.9meter | 6.1meter | 7.3meter |
| Max diameter: | 16Ft | 20Ft | 24Ft |
| Wind load: | 11300m3/min | 12500m3/min | 14100m3/min |
| Fan weight: | 74Kg | 97Kg | 110Kg |
| Max speed: | 75rpm | 65rpm | 55rpm |
| Power: | 1.5Kw | 1.5Kw | 1.5Kw |
| Full load current: | 2.4A / 380V | 3.5A/380V | 3.5A/380V |
