Telescopic Extendable Windmill Turbine Blade Trailer
2023/12/09 22:17
| Loading Deck | 14500mm-35000*2500*1500mm | |
| Rated Capacity | 40-60Tons | |
| Tare Weight | 12-18Tons | |
| Total Weight | 52-78Tons | |
| Wheelbase | 1310mm | |
| Axles | 13T American Style | 3/4 sets |
| Tyre | 10.00R20;11.00R20;12R22.5 | 12/16sets |
| Rims | 12/16pcs | |
| Suspension | Air suspension with hydraulic steering & lifting functions, all accessories imported | |
| Brake | Dual line pneumatic brake system,T30/30+T30 air chamber; parking brake; | |
| Material | High Tensile Carbon Steel | |
| Size | Upper plate | 25mm |
| Lower plate | 25mm | |
| Mid Web | Box styled double 12mm | |
| Height | 500-520mm | |
| Floor | 4mm diamond plate | |
| Welding | automatic submerged arc welded | |
| King pin | 2’ or 3.5’ interchangeable | |
| Landing Gear | 28T with static 80Tons | |
| Lights | Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light | |
| Painting | Three coats painting; Any color will be available | |
| Tool Box | One tool box with a set of standard trailer tools | |
| Tyre Carrier | One piece | |
| Electrical | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) Euro Standard | |
